Brake Thermal Design

The general brake thermal design is to limit the theoretical temperature increase of brake after a hard
braking below a certain level and derive the proper brake dimensions. Equation (1) describes the
theoretical temperature increase in °C, of a front disc brake.
A typical thermal design goal is to limit the theoretical temperature increase to less than 230°C after a
complete stop from 128 km/h at 0.7 g deceleration and GVW. The use of a brake body material with high
specific heat and a solid disc brake help to meet this goal. Aluminum and its alloys are good candidate
materials for this application.
= theoretical temperature increase, °C

= the percentage rear braking

= vehicle weight, kg

= initial velocity, m/s

= final velocity, m/s

= gravitational constant, 9.8 m/s^2

= rotor body material density, kg/m^3

= rotor body material specific heat capacity, J/kg °C

= rotor body material volume, m^3
(1)
